Components
Technical specs
-
Frame
Chrono 29 Stealth full Carbon, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable routing, Boost 12x148mm rear axle, dedicated 1X drivetrain design, Flatmount brake compatible,
Sizes
S: 395mm / M: 430mm / L: 470mm / XL: 520mm
-
Fork
RockShox Recon Gold RL Remote 29, 120mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 30mm aluminum stanchions, offset 42mm. Settings: Onelock 2 pos remote compression (open/lock), rebound, air preload
Fork remote
RockShox OneLoc
-
Headset
Onoff internal IS52 1-1/2 head tube, ACB sealed bearings, top 52x42x7 45°x45°, bottom 52x42x7 45°x45°.
Stem
MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5º, length: S size: 50mm, M size: 50mm, L size: 60mm, XL size: 70mm
-
Handlebar
Onoff Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 760mm, 9º backsweep, 0º upsweep, 31.8mm barbore
Grips
Onoff Twin, 1lock-on, 135mm
-
Seatpost
Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm
Saddle
Mondraker MDK Series, SRX, steel rail
-
Front brake
Sram Level, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear brake
Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
-
Brake lever
Sram Level, tooled reach adjust, lever pivot bushings
Rims
Mavic CrossRide 29, 30mm internal width, sleeved rim, hookless, tubeless ready, 28 spokes
-
Spokes
Mavic J-bemd steel round spokes
Front hub
Mavic, Boost 15x110mm, IS 6 bolts
-
Rear hub
Mavic, Boost 12x148mm, ID360 Ratchet system, IS 6 bolts, HG freehub
Front tire
Maxxis Ardent 29x2.40, Dual compound, EXO, tubeless ready, 60TPI, folding bead
-
Rear tire
Maxxis Ardent 29x2.40, Dual compound, EXO, tubeless ready, 60TPI, folding bead
Crankset
Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S size: 170mm M size: 175mm L size: 175mm XL size: 175mm, CL 55
-
Rings
34T, steel, X-Sync 2
Bottom bracket
Sram DUB BSA, sealed bearings, 73mm
-
Chain
Sram SX Eagle, 12s, Powerlock
Rear derrailleur
Sram NX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
-
Shift levers
Sram Trigger SX Eagle, 12s, X-Actuation 1:1
Casette
Sram PG-1230, 11-50T, 12s
-
Derailleur hanger
Sram UDH
Weight
12,2 kg
