MONDRAKER DUSTY

2X CHAINRING COMPATIBLE

2X compatible frame.

INTEGRATED HEADSET CABLE ROUTING

The ONOFF stem and bar are designed to seamlessly integrate and guide the cables.

INTEGRATED SEATPOST CLAMP

The seatpost clamp is completely integrated into the frame by design.

DROPPED SEATSTAYS

The design of the seatstays offers unbeatable comfort while riding.

INTEGRATED CHAINSTAY PROTECTOR

Custom fitted rubber chainstay protector to keep your DUSTY scratch-free.

DUSTY CARBON FORK

Versatile carbon fork with a 12mm axle and hidden dropouts.

E-Shifters

Adjust the assistance level without taking your hands off the bars thanks to the remote shifters.

Wireless Pulsar ONE Display

Shows real-time ride data, battery level and assistance level at a glance. Totally integrated in the cockpit.

Head unit

Toptube integrated, shows your battery level or assistance level through a luminous display with Bluetooth connectivity and ANT+.

iX350, 350Wh integrated battery

Battery integrated into the frame, offering more than 180km of range and 2400m of altitude gain.

Mahle bottom bracket

360 EVO Pressfit BB with built-in torque meter and cadence sensors.

e185 X20 Range Extender

171Wh extra battery to offer more range for those longer rides while only adding 1kg to the bike. Increase your range by up to 50%.

Mahle X20 Motor

Mahle X20 hub motor offering 55Nm of torque. Natural riding feeling and 3 levels of assistance (WATTS ON DEMAND concept).

Automatic motor connection

Connect your motor automatically and simply when fitting the back wheel. All connections are integrated into the rear dropouts.

Cerrar info

WATTS ON DEMAND

Natural pedalling feel without changing the way you ride

The Mahle system with the X20 motor and its 350Wh integrated battery weighs only 3.6kg, and with 55Nm of torque it assists your pedalling naturally, without friction and with a super smooth start and stop to the assistance. We’ve collaborated with Mahle to create new Gravel specific firmware for the DUSTY which defines the characteristics of the assistance provided by the motor specifically for Gravel use. As a starting point we aimed to simulate at all times the effort made by the rider without the assistance of the motor in order to avoid losing the sensation of a natural pedalling feel. We call this concept “Watts On Demand“

We’ve set these three principle characteristics as our base:

Non-intrusive system.
Sufficient support to satisfy Gravel use.
“Unlimited” range.

As such, level 1 provides a continuous power support of 25%, level 2 goes up to 50% and level 3 goes all the way up to 200% (varying between 75% and 200% depending on rider input (torque)).

WATTS ON DEMAND

Natural pedalling feel without changing the way you ride

AS FAR AS YOU WANT TO GO

Integrated 350Wh battery for a more efficient system

With its 350Wh integrated battery plus the 171Wh range extender, how far you want to go depends on you, and only you. Add the power of your legs to the 250W output of the Mahle X20 motor and go climb mountains and traverse great distances on your DUSTY. From now on you decide how far you want to go.

SET NEW FRONTIERS

171Wh range extender in the shape of a water-bottle

The new DUSTY comes with a totally integrated range extender in the shape of a water bottle, which you can add for those longer than usual rides. Extra range in a small package.

THE ALL-PURPOSE FORK

The most versatile carbon fork

Our carbon fork is as versatile as the DUSTY it’s fitted to. All cables are run internally so as to avoid interfering with supports for bottles, bags or pannier supports. The fork comes with a standard Post Mount for the brake caliper, and comes with a 12mm through axle for maximum rigidity. Dropouts are minimalist and leave nothing exposed.

MORE TRAVEL, MORE DUSTY, MORE FUN

Add more comfort and safety to your ride

If you want more, we will give you more. The DUSTY XR, our top of the range DUSTY, comes with a 40mm RockShox Rudy fork as stock and a 75mm Reverb XPLR AXS seatpost too, so you can take your DUSTY down the trails other gravel bikes wouldn’t dare go down. Sometimes everyone else is wrong and everywhere is DUSTY territory.

NO CABLES ALLOWED

Design and function combined in full integration

The ONOFF bar and stem fitted to the DUSTY hide the cables away 100% internally. No outer cables bothering your grip on the bars, nothing to spoil the spectacular minimalist design of the DUSTY.

YOUR TIRE, YOUR STYLE

You decide how wide you want to go

Both frame and fork allow for up to 47mm width tyres, so only you decide how wide you want to go. The DUSTY R and RR come with 40mm tyres for more speed on compact terrain, and the DUSTY XR comes with 45mm tyres so you can get off the beaten track more than once in a while.
